Fowler Bed Full Gatch

Description

The Fowler Bed Full Gatch is a highly durable medical bed featuring a four-section lying area. The top section is constructed from high-quality mild steel strips, while the fixed portion is made from reinforced steel sheet for maximum structural integrity.

Positioning is controlled through two manual hand cranks, allowing for precise adjustments of the backrest (0-80°) and knee section (0-40°) to reach the full Gatch position. The bed frame is made of rectangular mild steel box section and finished with a pretreated epoxy powder coating to ensure it is rust-resistant and easy to disinfect. For added patient safety and clinical utility, it features detachable head and foot boards and side guard rails.

Sub Products (Objects Included)

• Mechanical Hand Cranks: Two manual cranks for independent backrest and knee rest adjustments.



• Detachable Head/Foot Boards: Removable panels for easier patient access.



• Side Guard Rails: Included on both sides for patient security.



• High-Quality Castors: Four 125 mm diameter wheels, with two featuring locks for stability.



• 4-Section Lying Base: A combination of MS strips and reinforced steel sheets.



Quantity

• Total: 1 Complete Fowler Bed Unit.



• Dimensions: Overall size of L 2100 mm x W 900 mm.



• Optional Add-ons: Arrangements for mosquito poles and I.V. stands are available on specific demand.
